1. Rewinding equipment:

Structure:

(1).Surface rewinding (Double work-station ,Non-stopping)

(2).Surface rewinding roller is drived independently

(3).Drive motor

(4).Frequency speed control

(5).Rewinding shaft be pressed by compcting cylinder

(6).Hydraulic pressure edge regulating

Characteristic:

(1)Rewinding diameter: Φ1300mm

(2)Inside dameter of base material : 3inch

(3)Width of film coating: 1250mm

(4)Surface rewinding roller, high degree of accuracy

(5)chrome Plated rollerΦ510

(6)7.5kw planetary speed reducer ,motor

(7)7.5kw frequency converter

(8)Rewinding shaft press compcting cylinder: Φ80mm

Air-swollen feeding shaft

6. Guide roller: Φ120~80×1300 mm

7 .Pneumatic: all are excellent quality, gas circuit can be controlled in the first touch.

8.Low-voltage components: all are UC Certified products.

9. Whole machine is touch-sensitive screen man-machine interface.

10. Power: 3 phase 380V 50Hz (three phase four wire system)

Barometric pressure: 6~8/kg/cm2

Water pressure: 2~3kg/cm2

2. Control unit

1. Frequency control of motor speed

2. Rewinding shaft air clamper

3. Other equipment

4. All balancing aluminum guide roll Guide roller: ∅90—120×1300mm

5. The rack adopts the wallboard structure

6. Pneumatic: all are excellent quality, gas circuit can be controlled in the first touch.

7. Cylinder (Taiwan)

8. Low-voltage components: all are UC Certified products.

9. Automatic mechanical transmission system (main motor, composite, the winding motor)
